본문 Specification Items CD-400A Equipment Length of equipment 10.3m Width of equipment 2.38m Height of equipment 3.75m Frame of car Daewoo 5ton Boom Volume of boom 5 section(direct boom)+3 section(refractive boom) Length of boom 7m+2.8m Method Interlocking 5 stage boom(direct)+Interlocking 3 stage boom(refractive) Turn Table Rotation 350 degree ratation Form Hydraulic driven Outrigger Slider Form 3stage in Forward and backward with hydraulic system Stroke Front 1300 Back 1300 Extended range Width(front, back) 7720 Length(left, right) 7260 Outrigger Stroke 950 Working table Size Width×Length×Height 0.71m×1.74m×1.1m Form Electrical operation Rotation 540 degree ratation Control System Wire system Option Wireless control Basis Height of equipment Floor height of Working box 39.2m Maximum Working height 41.2m Maximum working Weight 300kg Remarks The specifications of the product for reasons such as better performance and is subject to change.
